Accessories
Brass thread adaptor from M25 male to M28×1 female, 9 mm thread length, for fitting M28×1 hose parts to an M25 entry.
Accessories
Swivel adaptor connecting the AISI 316 flexible hose to the M28×1 transition unit on wall mounted heat trace junction boxes.
Ex e brass gland M25 with M28×1 adaptor for the flexible hose and silicone grommets for heating cables.
Caution label marking the position of a heating cable splice under the insulation. Norwegian and English text.
Caution label marking the position of a heating cable end seal under the insulation. Norwegian and English text.
Caution label warning that the pipe or vessel is electrically heat traced. Norwegian and English text. Fitted on the insulation cladding at regular intervals.
Stainless steel clamp holding two self-regulating heating cables of 5 × 15 mm, or Ø 10 mm cable, against the pipe or structure. 0.2 kg. Drawing 784A109624.
Wall mounting connection kit that brings the PT100 sensor cable (Ø4.5–9.1 mm) into the thermostat or junction box.
Ex e certified drain and breather plug M25 in brass with lock nut, for heat trace junction boxes and thermostats. IP66.
Brass terminator closing the flexible hose at the pipe end, for pipe mounted installations.
Stainless steel flexible hose, M25/M28×1, protecting the heating cable between the pipe insulation and a wall mounted junction box. 2 m length.
Stainless steel flexible hose, M25/M28×1, protecting the heating cable between the pipe insulation and a wall mounted junction box. 25 m roll.
Silicone grommets with pressure nut for high-temperature heating cables in the pipe mounted TEF 1058 box transition unit.
M25 gland and grommet kit that protects a high-temperature heating cable where it enters a wall mounted box, without Raychem termination kit.
M20 gland with flexible hose adaptor for PT100 sensor cables of Ø4.5–7.5 mm.
M20 protection kit for PT100 sensor cables of Ø4.5–7.5 mm on wall mounted thermostats.
M25 gland with flexible hose adaptor protecting the PT100 sensor cable (Ø4.5 mm) between pipe and thermostat.
M25 gland with flexible hose adaptor protecting the PT100 sensor cable (Ø8 mm) between pipe and thermostat.
Accessories
Teflon (PTFE) strip laid under the heating cable on rough or hot surfaces as a protective layer. 40 × 2 mm, sold per 10 m roll.
Stainless steel pipe strap for fixing heat trace junction boxes and heating cable accessories to pipes of 1/2" (Ø20–47 mm).
Stainless steel pipe strap for fixing heat trace junction boxes and heating cable accessories to pipes of 3/4"–1 1/2" (Ø40–90 mm).
Stainless steel pipe strap for fixing heat trace junction boxes and heating cable accessories to pipes of 2"–8" (Ø60–280 mm).
Stainless steel pipe strap for fixing heat trace junction boxes and heating cable accessories to pipes of 3"–18" (Ø60–540 mm).
Aluminium tape applied over the heating cable to improve heat transfer to the pipe and hold the cable in place. 50 m roll.
Cold-applied connection kit for Raychem parallel (self-regulating and power-limiting) heating cables. Ex eb IIC Gb, IP66, max. 277 V.
Cold-applied termination kit for connecting the heating cable in an M25 gland without a heat gun. Ex eb IIC Gb, IP66.
Accessories
Heat-shrink termination kit that prepares the heating cable for connection in an M25 gland. Ex eb IIC Gb, IP66, −55 °C to +110 °C.
Cold-applied universal end seal mounted above the insulation, so the termination stays accessible for inspection. II 2 G Ex eb IIC Gb, IP66.
Cold-applied universal end seal for BTV, QTVR and XTVR heating cables, fitted below the insulation. Ex eb IIC Gb, IP66, −55 °C to +56 °C.
Heat-shrink end seal kit closing the far end of a Raychem BTV or QTVR self-regulating heating cable. Rated −60 °C to +110 °C.
Heat-shrink end seal kit for the high-temperature Raychem cables XTVR, HTV, KTV and VPL. Rated −60 °C to +260 °C.
Heat-shrink end seal for the Raychem VPL power-limiting heating cable.
Electronic heat tracing controller with display, alarms and communication, for zone 1 and zone 2. Ex eb ib mb [ib] IIC T4 Gb, IP66, 90–305 V AC, −50 °C to +60 °C.
As Elexant 5010i with an independent safety temperature limiter, for circuits that require a limiter by design (stabilised design or high-temperature cables).
Electronic thermostat with PT100 line sensing for high-temperature heat tracing, 0–499 °C range, with status light.
Silicone protective sleeve for heating cables where they pass sharp edges, cladding or supports. 25 m roll, price per metre.
Polyamide M25 cable gland for power cables of Ø8–17.5 mm into Raychem junction boxes. II 2 GD Ex eb IIC Gb.
High-temperature glass cloth tape for fixing heating cables, rated to 260 °C. 16 m roll. Suitable for stainless steel pipes.
Glass cloth tape for fixing Raychem self-regulating heating cables to pipes and vessels. 20 m roll. Not for use on stainless steel.
Chemelex RAYCHEM polycarbonate junction box for heat tracing circuits, 750 V, IP66, −35 to +115 °C. 0.47 kg.
Polymer universal junction box with three M20 and one M25 entry, IP66, max. 590 V, −55 °C to +55 °C.
Polymer pipe mounted junction box for up to three Raychem heating cables with cold-applied connections. Ex eb mb IIC Gb, IP66, max. 277 V.
Polymer junction box with integrated cold-applied connection for one Raychem heating cable, mounted directly on the pipe. Ex eb mb IIC Gb, IP66, 110–277 V.
As JBS-100-E, with a green indication light showing that the circuit is energised. Ex eb mb IIC Gb, IP66.
Accessories
Glass-fibre reinforced polymer junction box with four M25 entries for Raychem modular connection systems. II 2 G Ex eb mb IIC Gb, IP66, max. 480 V.
As JBU-100-E with an internal earth plate for braided cables. Ex eb mb IIC Gb, IP66, max. 277 V.
Multilingual warning label for VPL power-limiting heating cable installations with stabilised design temperature classification.
Accessories
Raychem MONI-PT100-260/10 temperature sensor – Ø6 × 60 mm element, 10 m PTFE cable, M16 gland
PT100 3-wire temperature sensor for electronic thermostats and controllers in zone 1: Ø6 × 60 mm element, 10 m Ø4.5 mm PTFE cable, M16 Ex e gland, rated to 260 °C at the element.
Accessories
Raychem MONI-PT100-260/15 temperature sensor – Ø6 × 60 mm element, 15 m PTFE cable, M16 gland
Chemelex RAYCHEM 3-wire Pt100 sensor with 15 m braided PTFE cable and halogen-free M16 polyamide gland, −50 to +260 °C, for intrinsically safe circuits in Zone 1/21 and Zone 2/22 or non-hazardous areas.
Accessories
Raychem MONI-PT100-260/2 temperature sensor – Ø6 × 60 mm element, 2 m PTFE cable, M16 gland
Chemelex RAYCHEM 3-wire Pt100 sensor with 2 m braided PTFE cable and halogen-free M16 polyamide gland, −50 to +260 °C, for intrinsically safe circuits in Zone 1/21 and Zone 2/22 or non-hazardous areas.
Accessories
Raychem MONI-PT100-260/25 temperature sensor – Ø6 × 60 mm element, 25 m PTFE cable, M16 gland
PT100 3-wire temperature sensor for electronic thermostats and controllers in zone 1: Ø6 × 60 mm element, 25 m Ø4.5 mm PTFE cable, M16 Ex e gland, rated to 260 °C at the element.
Accessories
Raychem MONI-PT100-260/5 temperature sensor – Ø6 × 60 mm element, 5 m PTFE cable, M16 gland
PT100 3-wire temperature sensor for electronic thermostats and controllers in zone 1: Ø6 × 60 mm element, 5 m Ø4.8 mm PTFE cable, M16 Ex e gland, rated to 260 °C at the element.
Accessories
Raychem MONI-PT100-EXE temperature sensor – high temperature, 2 m MI cable with M16 gland
Chemelex RAYCHEM Ex e Pt100 sensor for high temperature exposure, with 2 m mineral insulated (MI) cable in stainless steel AISI 316L and M16 gland, IP66.
Accessories
Raychem MONI-PT100-EXE temperature sensor – high temperature, MI cable with junction box
Chemelex RAYCHEM Ex e Pt100 sensor for high temperature exposure, with mineral insulated (MI) cable and junction box, stainless steel AISI 316L, IP66.
Chemelex RAYCHEM NGC-20 single-circuit electronic controller in a glass-fibre reinforced polymer enclosure for hazardous areas, −40 to +60 °C, 50/60 Hz. 3.7 kg.
Accessories
Raychem NGC-20-CL-E electronic heat tracing controller with limiter – Ex e, single circuit
Chemelex RAYCHEM NGC-20 single-circuit electronic controller with independent temperature limiter, in a glass-fibre reinforced polymer enclosure for hazardous areas, −40 to +60 °C, 50/60 Hz. 3.7 kg.
Mechanical capillary thermostat in cast aluminium for switching heating cable circuits in hazardous areas. Ex db IIC T6 Gb, IP66, max. 480 V, −40 °C to +60 °C.
Cold-applied universal in-line splice for Raychem self-regulating heating cables. Ex eb IIC Gb, IP66, max. 254 V.
Heat-shrink in-line splice joining two lengths of BTV or QTVR (and TLT) heating cable under the insulation. −60 °C to +110 °C.
Heat-shrink in-line splice for the high-temperature Raychem cables XTVR, KTV, HTV and VPL.
Cold-applied junction box for splicing or tee-connecting Raychem heating cables under the insulation, with crimp connectors.
Accessories
Stainless steel splice joining two lengths of the AISI 316 flexible hose. M28×1.
Stainless steel bracket with engraved Trafolyte tag for marking heat trace junction boxes and circuits.
Accessories
Stainless steel protector fitted where the heating cable passes a cladding edge, preventing the sheet metal from cutting into the cable.
Accessories
TEF 7211-A Flange Crossing Protector with silicone sleeve – flange size 27–40 mm, AISI 316
Stainless steel bridge with silicone protection sleeve that carries the heating cable over a flange of 27–40 mm without kinking or chafing.
Accessories
TEF 7211-B Flange Crossing Protector with silicone sleeve – flange size 37–50 mm, AISI 316
Stainless steel bridge with silicone protection sleeve that carries the heating cable over a flange of 37–50 mm without kinking or chafing.
Accessories
TEF 7211-C Flange Crossing Protector with silicone sleeve – flange size 50–95 mm, AISI 316
Stainless steel bridge with silicone protection sleeve that carries the heating cable over a flange of 50–95 mm without kinking or chafing.
Accessories
TEF 7211-D Flange Crossing Protector with silicone sleeve – flange size 95–140 mm, AISI 316
Stainless steel bridge with silicone protection sleeve that carries the heating cable over a flange of 95–140 mm without kinking or chafing.
Stainless steel exit plate that leads the heating cable out through the insulation cladding with a single bend, M25.
Accessories
TEF 7730 Cladding Penetration System M25 for HT cables 5×11/5×13/5×15 – no termination kit
Complete cladding penetration for high-temperature heating cables: M25 gland, cladding penetration fitting and grommets for 5×11, 5×13 and 5×15 mm cables.
Accessories
Cladding penetration fitting with M28×1 entry for the flexible hose, letting the protected heating cable pass through the insulation cladding.
Stainless steel exit plate with double bend, M25, for leading the heating cable out through the cladding parallel to the pipe.
Accessories
Mounting set for fitting a heat trace junction box across two parallel pipes.
Stainless steel spacer that lifts the pipe mounted TEF 1058 heat trace junction box or end seal away from a hot pipe.
Stainless steel spacer for the wall mounted TEF 1058 heat trace junction box on hot lines.
Weld-in socket in acid-proof stainless steel AISI 316 for joining two Ø 27 mm conduit pipes carrying heating or power cable, with a strong watertight weld and no burr inside the pipe.
Weld-on entry kit that takes a self-regulating heating cable (5 × 11, 5 × 13 or 5 × 15 mm) watertight into a hand rail, with integrated cable gland and silicone grommets. 0.4 kg.
Fixed 100 Ω reference resistor with heat-shrink sleeve, simulating a PT100 sensor at 0 °C for testing the ThermoConnect TTC controller and limiter.
3-wire Pt100 line sensing probe for heat tracing thermostats and controllers: Ø 6 × 60 mm tip, 300 mm element, −35 to +500 °C, Ø 5 mm silicone cable in 3, 5, 10 or 15 m, IP66. Select the cable length below.
