Datasheet TEF 10581105 HT JB End seal IECEx Pentai
TEF 1058 Heat Tracing End Seal termination w/light – Pipe mounted – Ex – Bright chemical dip AISI316
Type 1058 End Seal, Heat Trace w/ Indicator Lamp
Zone 1, Zone 2 & Safe Area
| Weight | 1 kg |
|---|---|
| Dimensions | 257 × 203 × 88 mm |
| Material | AISI 316L |
| SAP-Number | 325257 |
| Surface Treatment | Bright chemical dip |
| Weight | 1 |
| Operating Temperature | -50deg. C to +50deg. C |
| IP Rating | IP66 |
| Voltage | 12-254V |
| IECEx certificate no. | PRE 14.0001 |
| IECEx Protection | Ex eb IIC |
| ATEX Certificate | 14ATEX4124 |
| ATEX protection type | Ex eb IIC |
| T Class | T5 |
