The TRANBERG® TEF 2650 LED55 is the 420 W LED searchlight that replaces the TEF 2650 halogen 2000 W: a fully sealed aluminium-cast light module with 84 LEDs behind hardened glass, on a stainless steel motor housing with self-regulating heating, all white powder coated RAL 9010 at 70–80 µm. Two beams in one searchlight: a high beam of 3.5 million candela at 3° for long range, and a low beam of 0.5 million candela spread 4.4 × 15.2° for working close to the vessel; combined they give 4 million candela and 35 000 lm with a range of 2 500 m at 1 lux. Network operated from 1 to 16 Commander panels, −40 °C to +50 °C, IP56. Developed and manufactured at our own factory.
Application
- Fishing boats, rescue vessels, tugboats, supply ships, cargo and tank vessels
- Safe area; direct replacement for the TEF 2650 halogen 2000 W on the same network
Features and benefits
- High beam 3.5 Mcd at 3° and low beam 0.5 Mcd at 4.4 × 15.2°, or both combined
- Applicable to sub-zero temperatures down to −40 °C, self-regulating heating in the motor housing
- Electromagnetic compatibility (EMC)
- Operated from 1 to 16 control panels on the RS-485 network, control panel TEF 2613
- Fulfils the FiFi requirement (size 51 version)
Light performance (TPS7788)
| Low beam | High beam | Combined | |
| Lumen output | 15 000 lm | 20 000 lm | 35 000 lm |
| Peak intensity | 500 000 cd | 3 500 000 cd | 4 000 000 cd |
| Divergence | 4.4 × 15.2° | 3° | 3 × 4.3° |
| Range at 1 lux | 700 m | 1 850 m | 2 500 m |
| Current at 230 V AC | 0.6 A | 1.1 A | 1.8 A |
| Power | Max. 140 W | Max. 245 W | Max. 415 W |
Technical data
| Light source | 84 LEDs, 6 500 K |
|---|---|
| Control panel | TEF 2613 Commander, 1–16 panels |
| Material | Fully sealed aluminium-cast light module with hardened glass; stainless steel motor housing |
| Finish | White powder coated RAL 9010, 70–80 µm |
| Input voltage | 230 V AC (202–254 V AC); other voltages on request |
| Line input current | Max. 1.8 A |
| Pan / tilt | 370° / +20° to −30° |
| Cable glands | 2 × E204/622 M20/C2 (Ø 6.0–10.0 mm) and 1 × E204/622 M32/E1 (Ø 20.0–26.5 mm), brass |
| Ingress protection | IP56 (EN 60529) |
| Operating temperature | −40 °C to +50 °C |
| Weight | 50 kg |
All light data is measured and simulated. The user manual TUM7831 is listed above the table. For the 400 W version with a single beam, see the TEF 2650 LED51; the control panels are the TEF 2612 and TEF 2613.
